How to set up Tricolor?

It's not a secret for anyone that the package of TV channelsTricolor TV received a mass veneration and distribution, and was generally well received by consumers. However, in every barrel of honey there is a spoonful of tar, and this spoon is how to set up a tricolor for watching your favorite programs. But, this is not an excuse to be sad. You can customize tricolor TV yourself and this will not cause any special difficulties.

First we'll set up the satellite. This is necessary in the event that the assembly and installation of equipment is carried out independently. And also if you need to tv3 to tricolor for viewing channels. If the satellite is configured, you can immediately go to the channel settings.

Satellite installation

You can start searching for a signal. The degree of the signal will be reflected in the 2 lines-indicators with the numbers on the lower right side of the receiver's angle.

What do you need to achieve? Your task is to adjust the mirror so that these bands have the largest numerical value (normally 90 for the upper band and 60 for the lower band, although even better for the highband and 72-76 for the lower band). First, the numerical values ​​are the same, equal to "0".

First, you need to find any signalsign from the satellite. To do this, turn the plate slowly on the bracket from the South to the East. Turn the steps as slowly as possible, in millimeters. Remember that the more "step" becomes, the more it is possible to skip a signal sign from the satellite and not see your own mistake.

In addition, the sign does not appear immediately, but about a second after the pointing (if it does, naturally).

General strategy

To adjust the tricolor channels to the desired mode,we move the plate by a millimeter, wait for a couple of seconds if the signal sign does not appear. If the sign does not appear, do the next step. If the plate has already been moved in this way, which turned out to be 45 degrees, it means that you missed the signal by the signal, and you can start moving backwards.

If this is for you the first experiment in the configurationsatellite dish, then there is nothing unusual that you could not immediately catch the satellite signal and the satellite itself. The first 2-3 times still all the newcomers miss, the most important thing is not to limp.

Hooray! The signal is caught! However, here's a failure - the bands have an extremely small numerical value. Shift left and right (just a little bit!) Does not increase the value of the test strips. This means that you need to try to change the angle. Try to tilt down or opposite to raise. Thus, print the largest numerical value on the test strips.

If the signal strength does not increase, then it is worthto ascertain whether there are obstacles in the given direction in the form of shapes, houses, or crowns of trees. It is also worth checking the correct connection of the cable to the receiver and the converter.

When the value of the indicators has become large (this is notit must be 100/100!), as much as possible to secure the angle of roll, we will touch it more and will not change. On the bracket, take the risk that later it would be easy to find this position. Also tighten the screws on the bracket so that the mirror no longer moves.

Even if you no longer need to turn a mirror,this label will undoubtedly help in the future to adjust the tricolor independently and quickly find the satellite, even if the antenna moves from the established place, for example, under the influence of wind.

How to set up tricolor on your own

Now that the signal sign is caught, it is already possiblestart to search for channels. Here you need to see that the guys from the Lodge traditionally prescribe all the channels on the receiver before purchase, so when you buy, you do not need to do this. Here is a list of frequencies and channels that come with it:

Express AM-22 53 * East

Name of the channel Signal frequency Flow rate Polarity
fifth channel 10980 5000 Horizon
Country of Soviets 11031 3750 Horizon
World music, First music, STS, Home, Muz-TV, Home + 2, STS + 2 11044 44951 Vertical
HTH, UTR 11096 6400 Vertical
Belarus TV 11161 5785 Vertical

These frequencies one after another, you need to start the scan in the "manual search" menu, then set the tricolor channels and save the found TV channels (read the instructions to the receiver).

All! The plate is set up.

Setting up the TV channels of the satellite dish tricolor TV

  • Connect the sat-cable by connecting it to the LNB in ​​the receiver. Connect the sensor to the TV (SCART or RF out).
  • If the receiving tank is connected to the firsttime, then after connecting to the network, the TV screen will display the section "Language settings" - click "Next". There is a section "Installing the AV output"; if necessary, change options, if not: click "Next".
  • We fall into the sub-section of the channel search, in whichBelow in the right-hand corner is the option scale on the satellite (signal quality and power). If your antenna is not installed on the satellite Eutelsat W4-install (the direction of the compass - south ± 10 °) according to the scale on the screen; a numerical value on the upper scale must exist at least 90%, on the lower-70%. Select "Search type" - "Tricolor TV" click "Next", go search, then set tricolor of channels and, when finished, "Save channels" - "yes" appears on the screen.
  • The matrix "Time setting" appears: "UTC shift +03. 00 "," Update from satellite - yes "," Year - current "," Month - current "," Day - today "," Time is current ". Click "OK".

How to set up packet tricolor channels

To configure the entire package of offered TV channels does not necessarily have to be configured and stored separately. There is an opportunity to do this simultaneously and immediately on the whole package of services.

  • On the remote, press the "Menu" button - on the screenthe "Setup" menu appears - enter the PIN (the default is set to "0000") - select "Automatic search" - then the configuration label appears, where in the "Search type" select "Quick", click "Start search" - "Save new channels "-" Yes. "
  • "Menu" - "Installation" - PIN 0000 - "Manual search"- all leave unchanged, in the field "Frequency" - dial 12174, "Polarization" - on the left, "Stream of speed" - 4340, "FEC" - 3/4 "Start search" - "Save TV channels" - "Yes".
  • Further in the subsection "Frequency" we replace the value by 12207, "Polarization" - on the right, "Stream of speed" - 27500, "FEC" - 3/4 - "Start search" - "Save TV channels" - "Yes"
  • Then, in the "Frequency" section, replace the value with12360, "Polarization" - on the right, "Stream of speed" - 27500, "FEC" - 3/4 - "Start search" - "Save TV channels" - "Yes". Press the button "Exit" on the remote control 3 times.
  • In order to mark only the working channels from the list of 150 channels, it is necessary to find in the instruction a section to the receiver "Arrange favorites".

The abundance of items in the proposed instruction is notfrightening. The phased passage of each of them will not cause much difficulty. At the end of the whole process, the tricolor TV setting will be completed. Just strictly follow the sequence of actions.
