DIY caterpillar for a snowmobile or car. How to make a caterpillar with your own hands?

The caterpillar with its own hands can be made by any master. If you have long thought about how to make a caterpillar, then you should read the recommendations presented. For work, you can use a variety of tools and materials. It is permissible, of course, to use, if necessary, a caterpillar that was produced in a factory. But it will be much more expensive than if you make your own production. The article will present several options for manufacturing tracks, one of which you can choose for yourself.

Simple caterpillar production

do-it-yourself caterpillar
Caterpillar with his own hands can be performed on the most simple technology. It will take you a minimum amount of time. Crawler propulsion can be made on the basis of the stub-roller chain, as well as the conveyor belt.For the work you need to prepare some set of special tools or equipment. In order to extend the life of the tape, it is recommended to sew its edges with a fishing line, strengthening it at a distance of 1 cm. It is necessary to use the principle used by seamstresses to brush over the edges of the fabric, which will save the tape from damage.

Recommendations for the work

Caterpillars for the car do it yourself

The caterpillar with its own hands can be made by conjugating elements into a single ring, this can be done in several ways. So, it is permissible to use a hinge like a piano hinge, you can use a less reliable method, which involves stripping the ends of the ribbon. It is important to note that the tape thickness must be selected, which corresponds to the motor power. If you intend to use the engine from a motorcycle of domestic production, then you can apply the tape, the thickness of which is equal to 10 mm, according to the type used on agricultural conveyors.

If the caterpillar will be made using this technology, then you will not have to spend a lot of effort.Despite the fact that such a model of a caterpillar is made quite simply, it has a long service life and a long resource.

Making a caterpillar of automobile tires

snowmobile caterpillar do it yourself

You can make a caterpillar by yourself using tires. To carry out the work, it is necessary to pick up tires, borrowed from trucks, it is recommended to use a suitable tread pattern, while you will spend less effort when working with a tire. The manufacture of such a caterpillar should be made by cutting out tires from the sides of the tire, while leaving room for the treadmill. It is worth considering that this work is quite laborious and involves the application of a large amount of patience and effort, and you must use an exceptionally well-sharpened shoemaker's knife.

In order to make a smaller number of forces spent on making a caterpillar for a car with your own hands, it is possible to wet the blade from time to time using soapy water. As an alternative solution, you can use a device designed for cutting, it is permissible to use an electric jigsaw.On the latter, you first need to fix the file with small teeth, the file must also be pre-moistened with water, in the process, such manipulations must be performed periodically.

Technology of work

how to make a caterpillar with your own hands

Caterpillars for a car with their own hands should be made according to the technology, which involves the initial removal of the beads from the tires, then, if necessary, you need to remove the extra layers that are located on the wrong side of the formed ring, this is necessary if the track has increased hardness. If the tread pattern does not fit, then you need to cut a new structure, which will be necessary in order for the design to be able to cling to the soil.

Caterpillar for a snowmobile, made by the hands of the above scheme, will have many advantages, even if compared with the above option. This is because it has a closed loop, which indicates reliability. But there are also disadvantages, one of which is expressed in a limited width of a caterpillar, but if there is a need, then double width can be applied.

Making caterpillars from belts

making a caterpillar with your own hands
The next version of the caterpillar is especially attractive because in the process of carrying out the work it is not necessary to spend extra forces. Before starting, you need to prepare belts that have a wedge-shaped profile. They will have to be combined into one, using the hooks for the soil, which are fixed with screws, and rivets can be used as an alternative solution. The result is a caterpillar for a snowmobile, created with your own hands, which has holes designed for the drive sprocket. In order to form holes, it will be necessary to leave some space between the straps.

Another option for manufacturing tracks

Before you make a caterpillar with your own hands, you need to choose the technology of work. It is permissible to use the method presented below. The frame of propellers can be welded using pipes that have a rectangular cross-section. It is recommended to connect them using a frame, this will make the structure collapsible. The slotted part can be borrowed from the “Buran”, this will allow to make the drive shafts, you need to weld the slotted part of the shafts, which are borrowed from the “Oka”.It will be necessary to use brake discs. Working on the front shafts, you need to install brake mechanisms on them. Some part of the gear housing must be cut off. Making a caterpillar with your own hands will not only save, but also move around the snow-covered area without any problems. This design can be used for a long time without the need for repairs.
